Ntiaj Teb Tsum Ntawm Kev Tiv Thaiv Ib Puag Ncig
Thiab kev nyab xeeb cov kev daws teeb meem tshiab
Puag zaj duab xis rau Backlight Module
Muaj feem rau Backlight Module
● Cov tsis muaj
| Teem nqi | Ib yam | Scb1 / Scb2 | Scb3 / Scb4 | Scb5 | |||||
| Yam zoo | - | Brightening Zaj Duab Xis | Laminate zaj duab xis puag | Brightening Zaj Duab Xis(Nyias Hom) | |||||
| Qhov tuab | μm | 188 | 250 | 100 | 125 | 38 | 50 | 75 | |
| Lub zog tensile | MD | MPa | 169 | 168 | 182 | 172 | 220 | 176 | 204 |
| TD | MPa | 197 | 197 | 226 | 221 | 276 | 244 | 238 | |
| Elongation | MD | % | 160 | 187 | 162 | 162 | 137 | 170 | 179 |
| TD | % | 122 | 160 | 128 | 134 | 106 | 111 | 130 | |
| Kev shrinkage (150 ℃ / 30min) | MD | % | 0.93 | 0.88 | 1.02 | 0.94 | 1.4 | 0.56 | 0.91 |
| TD | % | 0.14 | 0.14 | 0.13 | 0.14 | 0.2 | 0.53 | 0.28 | |
| Kev hloov pauv | % | 90.4 | 90.2 | 92.1 | 92.1 | 90.9 | 91.2 | 90.5 | |
| Pos huab | % | 1.68 | 1.65 | 1.69 | 1.71 | 1.45 | 1.63 | 3.67 | |
